Melowave Premium Lightning Arrestor w/ Ground

SKU: MTA-3000
The Melowave MTA-3000 is an in-line lightning arrestor protector for antenna feed lines.

In stock

As low as: $29.99
Jump to: Description Reviews

Description / Melowave Premium Lightning Arrestor w/ Ground

The Melowave MTA-3000 is an in-line lightning arrestor protector for antenna feed lines.

  • Genuine Melowave in-line lightning arrestor
    • 0-3Ghz N Type Female to Male RF Surge
  • Characteristic Impedance: 50Ω
  • Frequency range: 0-3GHz
  • Dielectric Strength: 2500V rms
  • Dielectric Withstanding Voltage: ≥4000VRMS,50Hz,at sea level
  • VSWR: ≤ 1.2
  • Return loss: ≤ -26.4 dB
  • Insulation resistance: ≥5000MΩ
  • Material: Brass
  • Plating: Nickel plated
  • O-ring sealing: 6146 silastic
  • Insulator: PTFE
  • Temperature Range: -40°C~+85°C
  • Connector type: (Port 1) N female / (Port 2) N female
  • Max Surge Current: At least 10 times
  • Lighting Surge: current 20kA
  • Lighting Surge Current Waveform: 8/20 waveform
  • Protected Side Connector: N Female
  • Surge Side Connector: N Female
  • Mount Type: In Line
  • Model MTA-3000
  • Works with Melowave Antennas

More Information

Manufacturer Melowave
