TYT DWC30WIN 30A Switching Power Supply with LCD Display
Description / TYT DWC30WIN 30A Switching Power Supply with LCD Display
The TYT DWC30WIN is a compact, lightweight, high performance 30A switching power supply that lets you turn your TYT or other mobile two way radio into a base station. It is specifically engineered to minimize noise when used with devices for communication, including two way radios. It features a large LCD display with digital meter for high visibility.
- TYT switching power supply
- Model DWC30WIN
- AC Input Switch: 120V
- Output voltage: 13.8V DC - adjustable between 9.0 and 13.8V
- Output voltage regulation: less than 2%
- Protection: short-circuit - Automatic current limiting within 30A
- Output current: 30A(max) 20A(continuous)
- Ripple: less than 80mVp-p at rated load
- Fuse: 5A
- Meter: single volt/current meter - backlit LCD
- Dimensions: 155mm(W) x 70mm(H) x 205mm(D) (projections not included)
- Weight: approx. 1.5kg. (3.10 lbs.)
- Works with most mobile two way radios, including the TYT MD-9600, TH-7800 and TH-9800 Mobile Two Way Radio
- One year warranty
More Information
| Manufacturer | TYT |
|---|---|
| Type | Switching |
| Features | Amp Meter, Fan, Overload Protection, Volt Meter |
| Maximum Amps | 30 |
| Mount Style | Desktop |
| Warranty | 1 Year |
